Description
To the point
The LINSEIS TGA PT 1600 top-loading high-temperature thermobalance consists of a digital balance and a sample holder with integrated thermocouple.
- The thermobalance enables the measurement of samples with a weight of 5 or 25 g (including measuring system).
- Flexibility for all samples is ensured by interchangeable oven types (optional turntable for multiple ovens) for the wide temperature range from -150°C to 2400°C.
- Optional MS and/or FTIR coupling is possible at any time.
The optional, calculated DTA provides additional information on endothermic and exothermic reactions and can be used for temperature calibration.
Unique features
Wide temperature range
High resolution
Flexible design
Vacuum-tight system
Questions? We're just a call away!
+1 (609) 223 2070
+49 (0) 9287/880 0
Our service is available Monday to
Thursday from 8 am to 4 pm
and Friday from 8 am to 12 pm.
We are here for you!
Specifications
Hard Facts
MODEL | TGA PT 1600 |
|---|---|
| Temperature range: | -150 to 500/700/1000°C RT up to 1000/1400/1600/1750/2000/2400°C |
| Sample weight: | Max. 25 g |
| Resolution: | 0.5 ug |
| Vacuum: | 10E-2 mbar |
| TG - Sensors: | several to choose from |
| DTA - Calc: | included |
| Electronics: | integrated |
| Interface: | USB |
MODEL | TGA PT 1600 HIRES |
|---|---|
| Temperature range: | -150 to 500/700/1000°C RT up to 1000/1400/1600/ 1650/1750/2000/2400°C |
| Sample weight: | Max. 5 g |
| Resolution: | 0.1 ug |
| Vacuum: | 10E-2 mbar |
| TG - Sensors: | several to choose from |
| DTA - Calc: | included |
| Electronics: | integrated |
| Interface: | USB |
Available accessories
- Calculated DTA software
- Various gas boxes: manual, semi-automatic and MFC controlled
- Variety of crucibles (gold, silver, platinum, aluminum, Al2O3, graphite, tungsten, stainless steel (high pressure), etc.)
- Various rotary and turbomolecular pumps
- Optional gas analysis (coupling)
Software
Making values visible and comparable
The powerful LINSEIS thermal analysis software, which is based on Microsoft® Windows®, performs the most important function in the preparation, execution and evaluation of thermoanalytical experiments, in addition to the hardware used.
With this software package, Linseis offers a comprehensive solution for programming all device-specific settings and control functions, as well as for data storage and evaluation.
The package was developed by our in-house software specialists and application experts and has been tried and tested over many years.
TG properties
- Percentage (%) and absolute (mg/ug) change in mass
- Evaluation of the mass loss
- Residual mass determination
- 1st and
2nd derivative (peak temperature of the mass change)
General functions
- Real-time color display
- Automatic and manual scaling
- Display of the axes freely selectable (e.g. temperature
e.g. temperature (x-axis) against delta L (y-axis)) - Mathematical calculations (e.g. first and second derivatives)
- Saving complete evaluations
- Multitasking function
- Multi-user function
- Zoom option for various curve sections
- Any number of curves can be loaded on top of each other for comparison
- Online Help Menu
- Free labeling
- EXCEL® and ASCII export of measurement data
- Data smoothing
- Zero curves are offset
- Cursor function
- Statistical curve evaluation (mean value curve with confidence interval)
- Tabular printout of the data and expansion coefficients
- Calculation of Alpha Phys, Alpha Tech, relative expansion L/L0
- Curve arithmetic, addition, subtraction, multiplication
